2/0 AWG Solar Battery Extension Cable - Inverter And Battery Cable 2/0awg | Tinned Copper | 200ah| Red And Black 10FT Each

**10FT Length Red and Black 2Awg Tinned **

The 2/0awg cable is constructed of stranded tinned copper conductors, EPDM insulation, and a black CPE jacket. It is made for Solar equipment installations to act Solar Battery Cable or Solar Inverter Cable.This durable cable has a maximum temperature of 105°C and is rated at 600V. This cable's jacket is rated for continuous wet/dry exposure and resists oils, acids, alkalies, heat, and flame. It is also cRU certified which is CSA component compliant.

Amps	200
Approx LBS/MFT	293.00
AWG Size	2/0
Cond. Material	Tinned Copper
Conductor Stranding	161/24
CSA Type	cRU
Insul. Material	Ethylene Propylene Rubber (EPR)
Jacket Material	Chlorinated Polyethylene (CPE)
Jacket Thickness	0.045
Max. Temp	105C
Min. Temp	-40C
No. of Strands	161
Nom. Insul. Thick. (in)	0.065
Nom. O.D. (in)	0.5020 +/- 5%
Strand Size	24
UL Style	RHH/RHW
Voltage	600
